Machine Tools 24-7 Machine Quote - Click on the Machine ID Number Below to View Machine Photos Separately

Below are the specs we have on file for this machine.  Please contact Machine Tools 24-7 if you have any questions.

Machine IDYearManufacturerModelControl
155872011HaasST-30THaas Control

 DescriptionSpec Values
Capacity:Swing / Swing Over Cross Slide31.75" / 20.75"
 Maximum Turning Diameter / Maximum Turning Length21" / 26"
 Distance Between Centers26"
Spindle:Spindle Speeds Minimum - Maximum34 - 3,400 RPM
 Spindle Bore / Bar Capacity / Nose3.5" / 3" / A2-6
 Main Motor (30 min / continuous)40 / 35 HP
Turret:Number of Positions12 Stations
Travels:X-Axis Travel12.5"
 Z-Axis Travel26"
Tailstock:Stroke of Body / Quill24" / 3.1"
 Quill Diameter / Taper3.13" / MT #4
Rapids:Rapid Traverse (X & Z )945 IPM
Dimensions:Floor Space (L x W x H)162" x 88" x 96"
 Weight (approx.)14,000 Lbs

 Equipped With
Additional Info.:10" 3-Jaw Hydraulic Chuck
 Programmable Tailstock
 Chip Conveyor
 Two (2) Speed Geared Head
 Tool Setter
 Parts Catcher
 Rigid Tapping Note: 8,578 Servo, 5,280 Motion and 5,194 Spindle Hours
 Collet Chuck
 Coolant Through Tool
 Bar Feed Interface
 Haas Servo Bar 300 Bar Feed


Click Here To Print Quote - 15587

Click Here to Email Request Quote

TERMS: Cash or Cashiers Check with order, and all equipment is FOB on floor from sold location unless otherwise stated. All equipment subject to prior sales and is exclusive of any government tax. Equipment descriptions are intended only as a guide and their accuracy is not guaranteed. CONDITIONS: Item(s) are sold "As Is, Where Is" unless other arrangements have been made and conveyed in writing. There are no warranties, which extend beyond the description on the face hereof; quotation subject to change without notice. All agreements and/or contracts made by sales person are subject to approval. -EQUIPMENT SAFETY: It is the buyer's/user's responsibility to provide proper safety devices and equipment to safeguard persons from harm resulting from any particular use, operation or set-up, and to adequately safeguard the equipment conform to all Federal, State and Local Government Safety Standards and all Industrial Standards. - INDEMNIFICATION: Buyer/User agrees to Indemnify and hold harmless Seller and Salespersons from any and all claims or liabilities caused by or arising from the equipment on the face hereof. All equipment quoted is subject to prior sale. It is purchasers responsibility to verify machine condition, specifications and pay any and all applicable taxes./span>




ManufacturerModelMachine IDMachine Photos
HaasST-30T15587http://www.machinetools247.com/images/machines/15587-Haas ST-30T.jpg
HaasST-30T15587http://www.machinetools247.com/images/machines/15587-Haas ST-30T 1.jpg
HaasST-30T15587http://www.machinetools247.com/images/machines/15587-Haas ST-30T 2.jpg
HaasST-30T15587http://www.machinetools247.com/images/machines/15587-Haas ST-30T 3.jpg
HaasST-30T15587http://www.machinetools247.com/images/machines/15587-Haas ST-30T 4.jpg
HaasST-30T15587http://www.machinetools247.com/images/machines/15587-Haas ST-30T 5.jpg
